IBxxxxS-1W series has a fixed input and regulated single output.
Features:
SIP7 PACKAGE
Single Output
Industrial Standard PIN-out
Output Power:1W
1000VDC Isolation
Fixed Input
Regulated Output
PCB Mounted
Input Voltage: 5V/12/15/24 VDC
Output Voltage: 3.3/5/9/12/15VDC
Input Range: ±5%
Filter: Ceramic capacitors
All specifications measured at TA=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise specified.
COMMON SPECIFICATIONS
Items Testing condition Min Typ. Max
Operating Temperature Range -40°C +85°C
Storage Temperature Range -55°C +125°C
Humidity <90%
Cooling Free Air Convection
Leak Current <1mA
Isolation Voltage (VDC) Input to Output 1,000
Isolation Resistance (Ohms) 10
9
Isolation Capacitance (pf) 60
Efficiency (%) See Product List 60 68
Case Material Non-conductive black plastic
Potting Material Epoxy Resin UL94-V0
Packing Material Tube
Dimension (mm / inch) (L*W*H) SIP: 19.6*6.00*10.00 (0.77*0.24*0.39)
Weight (G) 2.0~3.0
MTBF (Hrs) >1,000,000
OUTPUT SPECIFICATIONS
Items: Testing condition Min Typ Max
Output Accuracy At full load and nominal Vin ±2%
Linear Voltage Calibration For Vin change of 1% ±1.2%
Load Voltage Calibration From 20% to full load ±8%
Ripple And Noise 20MHz bandwidth 50 mV p-p
Temperature Coefficient ±0.02 %/°C
Switching Frequency 125KHz
Short Circuit Protection Continuous Short Circuit Protection>20s
PRODUCT LIST
Part No. Vin(VDC)
Iin
(No-load)(mA)
Iin
(Full-load)(mA)
Vout
(VDC)
Iout
(max.mA)
Eff.
(%TYPE)
IB0503S-1W 5 22 220 3,3 200 60
