At the core of v16 is the PCM5 controller. It has a touchscreen interface for troubleshooting, fanless cooling, and embedded cyber security that is auto-configured and enabled by default.

Nymi Enterprise Edition authentication is a solution consisting of a multi-factor biometrically authenticated wearable (the Nymi Band) and a complete enterprise system for administration, management and integration into existing identity ecosystems.

The Model 71865 functions include two A/D acquisition IP modules for simplifying data capture and transfer. Each acquisition IP module contains a controller for all data clocking, triggering and synchronization functions.

This voice coil motor has a force to size ratio of 5.5 lbs (24.6 N) continuous force and 17.5 lb (77.7 N) of peak force with a housing measuring 2.000 in. (50.8 mm) dia. x 3.50 in. (88.9 mm) long.

CONTA-CLIP provides KDS-FB in four frame widths and with different divisions for flat and round cables. Sealing elements are available for all common industrial cable sizes.

The BML SF2 incremental encoder system is available with industry-standard A/B/Z quadrature or analog sine/cosine interfaces and is available in operating lengths of up to 48 meters.

The new integration to the EPLAN Cloud is available starting with Version 2.8. Designers can make the schematic project available in the cloud from the platform for downstream company processes.

Fitted with a 7th Generation Intel Core processor (Kaby Lake) and featuring up to 16GB DDR4 SODIMM memory, the PICO-KBU4 has the computing power to handle applications previously only possible with larger motherboards.

his technology allows FOC (field oriented control) for brushless motors without sensors from full stop to full speed under load. This HPSC uses a signal injection algorithm which determines the rotor position for a smooth startup.

Designed with an integral chuck to maximize work-zone volume and load capacity, the D200Z accommodates workpiece sizes up to 300mm in diameter and 210mm tall with weight up to 75 kg.

The Simatic RTU3000C telecontrol units are specially designed for energy-autonomous operation in environments without a power supply system. They can be supplied with power redundantly, for example with up to six battery modules or rechargeable battery with solar panel.

This latest edition of DriveWare now includes stepper motor configuration, allowing users to configure drives to run stepper motors in addition to the servo motors that were previously supported.

The automated thread checking solution from SMAC enables a detailed inspection and verification of all parts. It also identifies tool wear, and allows SPC data acquisition for process control and quality systems.

The SW-4000T-MCL features three custom CMOS line sensors with 4K (4096 pixels) resolution, mounted on anoptical prism assembly that precisely splits the incoming light into red, green, and blue wavebands.

The W16 and W26 were designed as smart sensors so they can be configured remotely via IO-Link. As smart sensors, W16 and W26 also offer additional diagnostic functions that can be used to predict maintenance and other smart tasks.

This KADL cable entry system allows for the insertion and sealing of pre-assembled cables with connectors into enclosures, machines and control cabinets.

Powered by an Intel Atom E3900 Series processor, the COM-APLC6 is designed for modern IoT applications. The module features two SODIMM sockets that support DDR3L-ECC memory.

The integral dust containment system provides operator access to the bag spout for connecting a full bag or disconnecting an empty bag, within a Dust Containment Box. Operator access to a positive shutoff valve to turn flow from the bag on and off as needed is provided within the Dust Containment Box.

The switches are designed to operate in harsh environments with varying climatic and environmental conditions, and is intended for digital substations, transportation and oil & gas industries.

The MiR500 is the same size as a standard Euro-pallet (47.2 in × 31.5 in × 5.7 in), and MiR expects that most MiR500s will be used to transport pallets in manufacturing floors and warehouses.

By implementing the iQ Monozukuri Andon system, all stakeholders within the factory can visualize the production status. It allows production managers to monitor the production status remotely and adjust the production plan accordingly. They can also set up announcements for changeovers.

Featuring a spiral bevel gear input to an inline planetary gear output, the EPR and PER are available in ratios of 3:1 to 1000:1 and a wide range of sizes and configurations.

The field controller can be used on its own or with a PowerFlex DC digital drive. In stand-alone mode, it provides power to a DC motor field with a fixed reference by using fixed I/O.

This latest release extends its existing Incoming & In-Process Quality Assurance capabilities to deliver Administrative Quality Management. Administrative Quality Management provides a total solution covering Corrective Action and Preventive Action (CAPA), Material Review Board (MRB), and Failure Reporting, Analysis, and Corrective Action System (FRACAS).

Chipkin’s BACnet Stack (CAS BACnet Stack) is a software library that allows users to add a native BACnet interface to embedded devices or applications.

These BES R01 flatpack sensors are designed to help to combat the conditions found in welding environments.

The platform’s connectivity and bandwidth deliver data back to the controller. This helps future-proof control systems for a Connected Enterprise. It is built on a 1 Gigabit architecture with communications supporting Device Level Ring (DLR), linear and star topologies.

The MXL2 with AMP includes two components produced by GE’s Additive Manufacturing Works (AMW) teams in Birr, Switzerland, and Greenville, South Carolina, United States: the first-stage turbine vanes and heat shields.

Powered by Savanna, Zebra’s data intelligence platform, MotionWorks is a portfolio of end-to-end solutions that integrate operational and edge data from multiple sources – including Ultra-Wideband (UWB), UHF RFID tags, Bluetooth Low Energy (BLE) beacons and cameras – to create insights that mobilize action to solve business needs.

The M12B cylindrical microscopy camera, based on the Sony Pregius IMX304 CMOS sensor technology, is a solution for customers requiring high resolution and focus with a larger sensor. Available in both color and monochrome, the 12 MP camera has a 1.1” lens format.

LA-20.6 series industrial AC-LVDTs operate from a nominal 3 Vrms, 2.5 - 3.3 kHz excitation source. They are packaged in a 0.812 inch (20.6 mm) OD SS housing with 12-inch leads, and are offered with either a metric or unified threaded 0.250 inch (6.4 mm) diameter core that works in a 0.313 inch (8 mm) ID bore.

All three optical sensors are offered in a 2.0mm x 2.0mm 0.5mm QFN package. The TSL2541’s package is made with a special dark compound which makes the device almost undetectable when mounted under inked cover glass.

Suitable for sensor applications including capacitive touch interfaces, the ATtiny3217 and ATtiny3216 have two Analog-to-Digital Converters (ADCs) that enable systems to implement touch control simultaneously with other analog measurements.

L-com’s OM4 and OM3, 24 channel, MPO fiber cables handle network throughput up to 100Gpbs (OM4) per fiber channel. Additional features include low-smoke zero-halogen (LSZH) cable jackets as well as full compatibility with US Conec MTP products.

This three-axis gimbal mount handles loads to 10kg (22.5 lbs) and has a clearance of 300 mm x 300 mm, (11.8 in. x 11.8 in.) around the roll axis stage.

The MTLT305D uses sensor fusion (Extended Kalman Filtering) and calibration algorithms to achieve 0.5 degree tilt and <10 milli-g acceleration accuracy in a variety of conditions.

uEye LE industrial cameras with twist-proof USB Type-C connection and practical USB power delivery are designed for logistics systems (e.g. for package acceptance and sorting), for microscopy and traffic monitoring as well as for installation in small medical or industrial devices.

Leveraged from the HTCA-6200, HTCA-6400 is designed with four CPU blades and four network I/O blades. Each of the CPU blades is empowered by two Intel Xeon E5-2600 v3/v4 CPUs and sixteen DDR4 R-DIMM sockets.

The TWR-015-346-2RC has a total angular displacement of 15 degrees [0.26 radians] and a motor constant of 34.4 in-oz/sqrt(watt) [0.24 N-m/sqrt(watt)] per coil or when coupled together the motor constant is 48.5 in-oz/sqrt(watt) [0.34 N-m/sqrt(watt)].

The devices are suitable for use with both brushed DC and brushless EC motors (BLDC) and come with comprehensive feedback options such as Hall sensors, as well as incremental and SSI absolute encoders

The dsPIC33CH is designed specifically to facilitate independent code development for each core by separate design teams and allows integration when they are brought together in one chip.

The OT1300 has the visualisation software integrated into the hardware, and is endurance tested as a complete system for 24/7 operation – including web visualisation via OPC UA. In conjunction with the atvise software, commissioning the OT1300 is a plug-and-play operation, even from a remote monitoring centre.

Microchip enables security by including chip-level tamper resistance, secure boot and secure key storage that, when combined with TrustZone technology, is designed to protect customer applications from both remote and physical attacks.

The AcuDew can be factory configured to provide an output corresponding to various moisture parameters including dew/frost point temperature, parts per million by volume or parts per billion by volume.

The kinematic arrangement of the a500Z minimizes the force path lengths through both the spindle as well as through the workpiece, efficiently transferring both cutting loads and reactive forces into the machine’s three point leveled bed

The IRB 6790 is aimed at high-pressure water jet cleaning applications in harsh industrial environments. The IRB 6790 allows cleaning of different part geometries in the same cell with zero changeover time

The 3/8″ Super Air Wipe produces a 360° airstream that can blow off, dry, clean or cool the material passing through it. The split design can be clamped around continuously moving material such as wire, cable, pipe, hose and extruded shapes.

The RS232 converter is designed for bi-directional communication, enabling communication over a variety of serial devices on the plant floor

The TEC 3 Series consists of 32 models offering inputs of 4.5~13.2 / 9~18 / 18~36 / 36~75 Vin and outputs of 3.3 / 5 / 9 / 12 / 15 / 24 / ±12 / ±15 Vout with efficiencies of 75-86%.

The AEC-Q100 grade 1 qualified AS5200L joins ams’ portfolio of magnetic position sensors, with its feature set focused at electrified powertrain drive-by-wire control functions, such as shift-by-wire for both traditional stick and rotary shifters, and pedal applications.

In the latest 2018.R1 release, TrendMiner's recommendation capability has been further extended with the addition of the fingerprint deviation tool.

The SMTS is used by automotive, autonomous, construction and off-highway vehicle OEMs and their associated steering suppliers for in-laboratory simulations of driver, road and vehicle inputs and their associated effects on steering system performance and annoying noises.

The R200 and R201 series offer photoelectric functional principles: thru-beam sensors, retroreflective sensors with a polarization filter or for clear object recognition, energetic diffuse mode sensors, sensors with background suppression and foreground suppression, measuring light barriers with two switch points, and distance sensors.

With diagnostics, dashboards and intelligence analytics, Measurement IQ works to enable operators to increase metering reliability in the face of skills shortages, dispersed operations and a complex hydrocarbon mix. Users can detect and correct mismeasurement and anticipate equipment failure.

ECP series 22mm pneumatic pushbuttons and switches are used with EVP series valve bodies to create manual valve assemblies, or hybrid electro-pneumatic actuators.

Each unit has performance specifications related to the guidelines published in Euramet cg-13 specifying stability, radial and axial uniformity, loading, and hysteresis.

Configurations include one-pole, one plus neutral, two, three and three plus neutral, with current ratings from 0.5A to 63A, all with thermal and magnetic trip elements for overload and short-circuit protection.

The Gecko Gripper, Polyskin Tactile Gripper, RG2-FT gripper and a technical upgrade of the HEX force-torque sensor product line based on OptoForce technology will open up new applications for collaborative robotics

Safety Manager SC is designed for global hydrocarbon processing companies with greenfield projects requiring SIL2 or SIL3 solutions for distributed and safety applications, or stand-alone safety solutions.

BISTel’s online DFD system offers manufacturers real-time monitoring and detection of full sensor trace data. Customers can now detect, and analyze yield impacting events and resolve yield issues. DFD® also integrates s to legacy FDC systems.

The CMV50000 is designed to provide the detailed views of a large surface area that are required in factory automation applications such as automated optical inspection (AOI) equipment and systems for the inspection of displays of mobile phones, tablets, laptops and TVs.

The 800 x 600 resolution DS701 Diagnostic Videoscope and 1200 x 720 resolution DS703 FC High Resolution Videoscope are built for industrial maintenance troubleshooting and quality assurance testing.

The 22ECT motor are powered by Ultra Coil Technology and multipolar rotor design, which provides torque of up to 41.6mNm. The 22ECT is a choice for applications such as humanoid robots, lab automation equipment, electric grippers, land surveying devices.

Features include programmable zero point offset, measurement averaging and sign of rotational direction. RFC4800 Series has a resolution of 14-bits across 360°, repeatability of 0.36° and independent linearity of ±0.5% of full scale.

Developed to meet the versatile nature of collaborative robots, Bimba’s CRVT comes off-the-shelf as a solution with no external valve required.

Designed to address PLC protocols such as ITU G.9903 (G3-PLC) and ITU G.9904 (PRIME), as well as CENELEC, FCC and ARIB compliant applications, the PL360B is the latest device in Microchip’s portfolio of smart energy products.

The new modular automation system is designed for pharmaceutical plants, biotech manufacturers, fine chemical factories and food and beverage industries. It is the first time that ABB offers a solution based on the modular automation concept to automate and orchestrate intelligent modules tailored to the plant’s manufacturing needs.

This system release leverages enabling technologies to eliminate a complexity barrier for small to mid-sized operations seeking to implement a DCS. By consolidating servers into a single machine, applications can implement the full functionality of a modern DCS.

The updates include extensive functionality for smart factories and energy distribution, as well as new predictive analytics calculations.

These converters are designed for healthcare products where small size and applied parts to patient (BF classification) is required.

The safety guard locking switch combines non-contact, coded-transponder safety technology with a mechanical solenoid locking function to create asolution to meet the levels of safety required by international standards.

The NCA-2512 is powered by Intel’s Atom C3958, offering up to 16 cores of processing prowess. The NCA-2512 also features 300W redundant PSUs, 10G interface for SFP+, SR-IOV support, Intel AES-NI and Intel QuickAssist Technology, running at 20G.

Simotics XP Chemstar low-voltage motors are used in machines and applications such as pumps, compressors, fans, extruders, agitators and separators.

Equipped with complete air cooling, the oil-free VARODRY screw pump is intended to make water cooling superfluous. The developers at Leybold were guided by the idea of using fewer, machine parts and components in their design.

The PR10 requires no external air supply so there are no air hoses to manage and the gripper works independently of changes in the pressure, cleanliness and availability of external air. With round edges, the PR10 is designed for collaborative implementation alongside human workers, using any of Universal Robots (UR) three models.

All these three cameras are connected to the base board using customized Micro-Coaxial cables. e-con Systems has designed a 30cm long Micro-Coaxial cable with connector locks at both ends, allows customers to connect both camera boards and adaptor board with no trouble.

The robotic add-on in combination with the EyeSens Match allows users to solve a pick and place application with an UR robot. The support of other robots with the EyeSens Vision Sensors will also be possible in the near future.

Models range in size from 0.75 to 2.25 inches (19 – 57 mm) in diameter. Rated speed ranges from 2400 to 19200 RPM, with rated power from 3 W to 62 W. Planetary gearhead models are available with output torque rated to as high as 62 Nm (8800 oz-in).

The PopLok VS Series is capable of forming 1-tuck and 2-tuck trays at speeds of up to 600 trays per hour.

The xTablet T1270 is a sunlight-viewable, IP65 sealed tablet is designed to stand up to extreme environments, while the i5-7000U processor allows for more complex operations including managing graphics and data.

The 1.25 pitch PicoBlade connector offers a connection in both wire-to-wire and wire-to-board applications. With four header options, the PicoBlade is intended to meet the design needs of products ranging from automotive media systems to healthcare applications.

The HART7 Sitrans P transmitters are ready for plant digitalization, giving users control and analysis through data logging functions and event control.

Three 32-point discrete I/O and five analog I/O expansion modules as well as three new temperature input modules have been added. Three 4-channel analog input and two 4-channel analog output modules are now available with current and voltage signal options.

In addition to the specification-driven workflow and class warranty, the process engineering with EB 2018 also has rule-based design. Here it can be specified what information is to be passed on from which object to where.

The CEC1702 IoT development kit with the DICE architecture comes with a programmable 32-bit ARM Cortex-M4 Controller and sample code to develop a secure, cloud-connected solution.

This cutting tool and insert system from ARNO USA is designed to optimize turning, grooving, parting-off and copy turning operations.

Averna’s DP-1000 Protocol Analyzer is a mixed-mode, dual DOCSIS 3.0/3.1 sniffer, allowing simultaneous capture and monitoring of channels of different types (DS 3.0, DS 3.1, US 3.0, US 3.1 channels).

Applications of these modules measuring 3.000 in. x 3.000 in. include: solenoids, valves, actuators, DC motors, electromagnets, hydraulics, LEDs, power amplifiers for electro-pneumatic proportional valves, and pressure and flow control valves.

These 1/8 NPT Stainless Steel Air Jets replace open tubes and pipe nipples on parts cleaning, drying and cooling operations. With temperature rated up to 400°F, they will produce up to 1.25 pounds of force upon a target.

Recent releases of Seeq have focused on enabling larger deployments through scalability features in the software by making the Seeq application easier to use. Seeq also announced their new Europe, Middle East, and Africa (EMEA) office will be led by Seeq Managing Director for EMEA Mike Purcell

The EX378B02 is equipped with a free-field microphone cartridge. It has a frequency range of 3.75 to 20,000 Hz. With the low-end noise-floor measurement capability of 15.5 dBA, it can measure accurately to 137 dB at the top end.

Using closed loop feedback and control technology, Applied Motion StepSERVO Integrated Motors create torque for acceleration in meeting faster machine cycles.

The Scalance M804PB is suitable for companies in the manufacturing industry such as mechanical equipment manufacturers (Original Equipment Manufacturers / OEMs) as well as for companies in the automotive, food & beverage, chemical and pharmaceutical industries.

The multi-site solution for cybersecurity management is based on Honeywell’s ICS Shield, which provides a top-down operational technology (OT) security management solution for securing connected industrial control system (ICS) environments with multiple physical sites and multiple automation equipment types.

The laser triangulation sensor delivers 2048 points per profile in a time of 25.000 profiles per second. “Laser triangulation“ means that, a camera is following a laser line which is projected onto the scan object and from that captured image the line profile and height information are calculated

The MAX22505 is a solution that combines USB fault protection (480Mbps) for industrial voltages, while being flexible to support either host or device applications including USB On-The-Go (OTG).

Expansion of the company’s global partner network is designed to better enable IT/OT integration in customer deployments; and global expansion provide CIOs and CISO’s around the world with the security expertise they need to better manage and reduce their OT risks.

This rating applies to terminal versions with 2 or 3 pins in alternating positions per pole. These provide the creepage distances required to maintain a higher amp rating.

The SES/SEM70/90 are motor feedback systems offered in 25 mm and 55 mm diameters that use holistic sensing capacitive technology, to minimize external influences such as electromagnetic interference and humidity.

This medical PC adopts a 10.1-inch WXGA TFT LCD display with a projected capacitive touch screen and 350 nits of brightness. The 10.1” WXGA medical grade computer has one 204-pin DDR3L-1600 SO-DIMM socket for up to 8 GB of system memory. It also provides a choice of two types of storage: a half slim SATA SSD and an mSATA.
